1000 Lumen Work and Trail Light with 105 Degree Pivoting Head

Quick Facts

• Max Output: 1000 lumens

• Beam Distance: 722 ft (220 m)

• Runtime: Up to 29 hours

• Modes: 4 brightness levels, strobe, SOS

• Adjustable Head: 105 degrees

• Weight: 4.83 oz with battery

• Battery: 18650 Li-ion (included)

• Charging: Magnetic USB

• Waterproof Rating: IP66

The Fenix WT25R is an adjustable head flashlight built for work, trail travel, and hands-free tasks. Its 105 degree pivoting head lets you drop light exactly where you need it, and the magnetic tail allows quick attachment to metal surfaces for stable illumination during repairs, camp chores, or night tasks. The large mode switch makes it simple to move through brightness levels, while the magnetic charging interface keeps charging clean and reliable. This is a compact, field-ready tool designed for accuracy, ease of use, and dependable output.

---

Built for Worksites, Vehicle Repair, and Trail Use

• Adjustable head sets light at precise angles for task work

• Magnetic base provides hands-free lighting on metal surfaces

• Magnetic USB charging cable connects quickly and securely

• Four brightness levels plus strobe and SOS for emergencies

• Battery level indicator keeps power management straightforward

• Lockout feature prevents accidental activation in pockets or packs

• Intelligent temperature regulation protects the light from overheating

• Impact resistant and rain resistant for dependable field use

---

Specifications

• Max Lumens: 1000

• Max Beam Distance: 722 ft (220 m)

• Max Runtime: 29 hours

• Lighting Modes: 4 brightness levels, strobe, SOS

• LED: CREE XP-L HI

• Color Temperature: Around 5550K

• Lens: Polycarbonate

• Size: 5.33 in L x 0.95 in head diameter x 1.16 in body diameter

• Weight: 4.83 oz with battery

• Battery: One 18650 rechargeable Li-ion battery (included)

• Included: ARB-L18-3400 battery, magnetic USB charging cable, lanyard, spare O-ring

• Construction: Aluminum body with IP66 rain and dust resistance

• Warranty: Limited Lifetime Guarantee from Fenix Lighting USA

---

How to Use

1. Press the large mode switch to cycle brightness levels.

2. Hold to access strobe and SOS.

3. Pivot the head up to 105 degrees to position the beam for hands-free use.

4. Attach the magnetic tail to metal surfaces when working in fixed positions.

5. Check the battery indicator before heading out.

6. Connect the magnetic USB cable to recharge the battery.

Simple controls and a pivoting head make it easy to adapt this light to any task.

---

FAQ

Can the WT25R operate while charging?
No. The light must be disconnected from the charging cable to operate.

How does the adjustable head work?
The head pivots through a 105 degree arc to align the beam with your work angle.

Is the WT25R fully waterproof?
It is IP66 rated, which means rain resistant and dustproof, but not submersible.
